Cisco Catalyst Express 500 Series User Manual

1-3
Getting Started Guide for the Catalyst Express 500 Switches
78-17084-03
Chapter 1 Getting Started Guide
Run Express Setup
Step 5
Press the SETUP button.
When you press the SETUP button, a switch
port LED begins blinking green.
Step 6
When a switch port LED blinks green,
connect your PC to that port.
The port LEDs on your PC and the switch
blink green while the switch configures the
connection.
Step 7
When the SETUP LED turns green, start a
browser session on the PC.
When you start a browser session on your PC,
the set-up window automatically appears. If
the window does not appear, check that any
proxy settings or pop-up blockers are disabled
on your browser and that any wireless client
is disabled on your PC. You might also need
to enter a URL in your browser, such as
cisco.com or another well-known website. If
you need help, see the Troubleshooting
section.
