Figure 23: Routing the RJ-45 Cables Connected to the Supervisor PIC
—
Option 3
Cable ties3Strap-down clips1
Supervisor PIC cable management bracket4RJ-45 cable bundle2
Cisco Converged Broadband Routers Hardware Installation Guide
26
Installing the Supervisor in the Cisco cBR Chassis
Cable Management for the Supervisor PIC in the Cisco cBR Chassis
