card 8/0 cBR-CCAP-LC-40G r-phy
card 9/0 cBR-CCAP-LC-40G r-phy
b) Add the configuration cable sup250-ifmod 10GE right before cable downstream freq-profile 0 to make sure the
SUP250 board is in 10GE mode after boot up.
cable profile rpd-event 1
enable-notify
cable sup250-ifmod 10GE
!
cable downstream freq-profile 0
lane 1 start-freq 90000000
c) Relocate the backhaul related configuration based on the numbering scheme listed in the above chart. The mappings
are Ten4/1/0 – Ten 4/1/7 (SUP160) as Ten4/1/2 – Ten4/1/9 (SUP250), Ten5/1/0 – Ten5/1/7 (SUP160) as Ten5/1/2
– Ten5/1/9 (SUP250).
d) Modify the bootvar to the correct value.
boot system bootflash:<image_name>
e) Save the configuration as a sup250.txt file.
Step 3
Copy the sup250.txt into eUSB.
Step 4
Copy the IOS image into eUSB.
copy
ftp://<username>:<password>@<server
ip>/dir/<image_name>
Step 5
Execute md5 check for IOS image.
verify /md5 usb0:<image_name>
Cisco Converged Broadband Routers Hardware Installation Guide
31
Installing the Supervisor in the Cisco cBR Chassis
Swap Supervisor 160G to Supervisor 250G 10GE Mode
