In the Cisco cBR-8 router,Note
•
Slot 4/1 for the Supervisor PIC corresponds to slot SUP0 for the Supervisor Card.
•
Slot 5/1 for the Supervisor PIC corresponds to slot SUP1 for the Supervisor Card.
Required Tools and Equipment
•
ESD-preventive wrist strap
•
Supervisor PIC or blank PIC for the Supervisor
•
3/16" flat-blade torque screwdriver
Step 1
Grasp the faceplate of the PIC with one hand and place your other hand under the PIC to support its weight.
Step 2
Carefully align the PIC with the plastic guides in the slot.
Step 3
Slide the PIC into the slot applying even pressure using both your hands until it is within an inch of full insertion.
Step 4
Open the ejector levers and fully insert the PIC into the slot applying even pressure on both sides until it mates with the
midplane connectors.
Cisco Converged Broadband Routers Hardware Installation Guide
39
Installing the Supervisor in the Cisco cBR Chassis
Installing the Supervisor PIC in the Cisco cBR Chassis

Cisco cBR Specifications

General

Category	Network Router
Redundancy	Yes
Remote PHY Support	Yes
Remote MACPHY Support	Yes
Operating System	Cisco IOS XE
Interface	RF
Supported Interfaces	Ethernet, RF
Management	SNMP, CLI, Web UI
Product Name	Cisco cBR-8 Converged Broadband Router
Form Factor	Rack-mountable
