To prevent airflow restriction, allow clearance around the ventilation openings
to be at least 3 inches (7.6 cm).
Warning
• A computer to manage the device either via the console port or via the web-based interface. for web
based interface the computer needs to support one of the following browsers:
• Microsoft Edge
• Firefox (version 82 or 81 or higher)
• Chrome (version 86 or 85 or higher)
• Safari over MAC (version 14.0 and higher)
Suitable for installation in information Technology Rooms in accordance with Article 645 of the national
Electric Code and NFPA 75.
Warning
Rack Mounting Switch
You can mount the switches on any standard size, 19-inch (about 48 cm) wide rack. The switch requires 1
rack unit (RU) of space, which is 1.75 inches (44.45 mm) high.
For stability, load the rack from the bottom to the top, with the heaviest devices on the bottom. A top-heavy
rack is likely to be unstable and might tip over.
Caution
To install the switch into a 19-inch standard chassis:
Step 1 Place one of the supplied brackets on the side of the switch so that the four holes of the brackets align to the screw holes,
and then use the four supplied screws to secure it.
Step 2 Repeat the previous step to attach the other bracket to the opposite side of the switch.
Step 3 After the brackets are securely attached, the switch is now ready to be installed into a standard 19-inch rack.
Get to Know Your Switch
2
Get to Know Your Switch
Rack Mounting Switch
