Step 7 Remove the screw template from the wall.
Step 8 Place the switch onto the mounting screws, and slide it down until it locks in place.Wall-mounting an 8-port switch
Figure 4 Wall-mounting an 8-port switch
PoE Consideration
Some switches support PoE while others do not. The switch models that support PoE have a P in their model
number, such as: CBSxxx-xxP-xx. If your switch is one of the Power over Ethernet (PoE) models, consider
the following power requirement.
The switch is to be connected only to PoE networks without routing to the outside plant.
Danger
Get to Know Your Switch
5
Get to Know Your Switch
PoE Consideration

Cisco CBS 220 Series Specifications

General

Layer	Layer 2
Jumbo Frame Support	Up to 9216 bytes
Series	CBS220
Ports	8
PoE	Available on some models
Management	Web-based, CLI, SNMP
Energy Efficient Ethernet	Yes
Mounting	Rack-mountable
VLAN Support	Yes (802.1Q)
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X, Port Security
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Certifications	CE, FCC
Uplink Ports	SFP
Operating Temperature	0°C to 40°C (32°F to 104°F)
Humidity	5% to 90% non-condensing
