Chassis pivot point2
Two screws securing handle to Power A bus bar3
Step 9
Tighten the Phillips captive screw that secures the tab on the left side of the power block to the chassis. See item 1 in
Figure 8: Power A Bus Bar Installed in Chassis, on page 14.
What to Do Next
After the Power A bus bar has been installed, install the upper grille support. Continue to the Installing the
Upper Grille Support, on page 15 for more information.
Installing the Upper Grille Support
This section describes how to install the upper grille support on the Cisco CRS Series Enhanced 16-slot Line
Card Chassis. For complete information on regulatory compliance and safety, see Regulatory Compliance
and Safety Information for the Cisco CRS Carrier Routing System .
Although the upper grille support is an exterior cosmetic component, it must be installed prior to installing
the upper chassis ground cable and the power shelves.
Prerequisites
Before performing this task, perform the following procedure:
Required Tools and Equipment
You need the following tools and equipment to perform this task:
•
6-in. long number 1 Phillips screwdriver
•
Upper grille support
Steps
To attach the upper grille support to the chassis, perform the following steps:
SUMMARY STEPS
1.
Attach the upper grille support to the front of the chassis. Use the screwdriver to install the six M4 flat
head screws, three on each side, to the chassis. See Figure 9: Attaching the Upper Grille Support to the
Chassis, on page 16.
