42 4024320 Rev A
How Do I Configure My DOCSIS Residential Gateway?
Setup Basic Settings - Fixed CPE IP Assignment Page Description
The following tables provide a description of the fields within the Setup Basic
Settings - Fixed CPE IP Assignment page.
Field Name Description
MAC Address The MAC address of the PC or device (for example, a
printer) for which you want to reserve a specific IP address
on the network
Assign to IP The IP address you assign to the PC or device for which
you want to reserve a specific IP address on the network.
Only MAC addresses within the range of the gateway's
DHCP address pool can be reserved with this feature.
Note: The factory configuration of your gateway sets aside
IP addresses 192.168.0.2 through 192.168.0.9 for static IP
addresses.
Function Keys
Key Description
Add Static IP Adds the Static IP address to the list of assigned IP
addresses
Remove Static IP Removes the Static IP address from the list of assigned IP
addresses
