98 4021196 Rev A
Front Panel LED Status Indicator Functions
Normal Operations (AC Power applied)
The following chart illustrates the appearance of the residential gateway front panel
LED status indicators during normal operations when AC power is applied to the
gateway.
Front Panel LED Status Indicators During Normal Conditions
Front Panel Indicator Normal Operations
1 POWER On
2 DS On
3 US On
4 ONLINE On
5 ETHERNET
1 - 4
On - When a single device is connected to the Ethernet port and no data is being sent
to or from the modem
Blinks - When only one Ethernet device is connected and data is being transferred
between the consumer premise equipment (CPE) and the wireless home gateway
Off - When no devices are connected to the Ethernet ports
6 USB
On - When a single device is connected to the USB port and no data is being sent to or
from the modem
Blinks - When only one USB device is connected and data is being transferred between
the consumer premise equipment (CPE) and the wireless home gateway
Off - When no devices are connected to the USB ports
7 WIRELESS
LINK
On - When the wireless access point is enabled and operational
Blinks - When data is being transferred between the CPE and the wireless home
gateway
Off - When the wireless access point is disabled by the user
8 WIRELESS
SETUP
Off - When wireless setup is not active
Blinks - When wireless setup is active to add new wireless clients on the wireless
network
