1010E1010Feature
Eight Gigabit Ethernet RJ-45
10/100/1000 BaseT
Each RJ-45 (8P8C) copper port
supports auto Medium Dependent
Interface Crossover (MDI/X) as
well as auto-negotiation for
interface speed, duplex, and other
negotiated parameters, and are
MDI/X-compliant.
The ports are numbered (from top
to bottom, left to right) 1, 2, 3, 4,
5, 6, 7, 8. Each port includes a pair
of LEDs, one each for connection
status and link status. The ports are
named and numbered Gigabit
Ethernet 1/1 through Gigabit
Ethernet 1/8.
Eight Gigabit Ethernet RJ-45
10/100/1000 BaseT
Each RJ-45 (8P8C) copper port
supports auto Medium Dependent
Interface Crossover (MDI/X) as
well as auto-negotiation for
interface speed, duplex, and other
negotiated parameters, and are
MDI/X-compliant.
The ports are numbered (from top
to bottom, left to right) 1, 2, 3, 4,
5, 6, 7, 8. Each port includes a pair
of LEDs, one each for connection
status and link status. The ports are
named and numbered Gigabit
Ethernet 1/1 through Gigabit
Ethernet 1/8.
You can use ports 7
and 8 as PoE+ ports.
PoE+ is first
supported in FTD
Version 6.5 and ASA
Version 9.13.
Note
Network ports
Not supportedPorts 7 and 8 are
PoE+ ports; first
supported in FTD
Version 6.5 and ASA
Version 9.13.
Note
PoE+ controller card
Accepts a standard Kensington T-bar locking mechanism for securing
the chassis
Lock slot
A small recessed button that if pressed for longer than three seconds
resets the chassis to its default state following the next reboot.
Configuration variables are reset to factory default, but the flash is not
erased and no files are removed.
Reset button
No
System power is controlled by the power cord; there is no power button.
To shut down the Firepower 1010 or 1010E, remove the AC power
supply.
Power switch
The chassis is powered on when you plug in the AC power supply.Power cord socket
Cisco Firepower 1010 Series Hardware Installation Guide
3
Overview
Features
