Cisco Firepower 1140 Getting Started

Explicit, implied, or default
configurationConfigurationSetting
Default.• Firepower 1010—The outside interface, Ethernet1/1, is a
physical firewall interface. All other interfaces are switch
ports that are enabled and part of VLAN1, the inside
interface. You can plug end points or switches into these
ports and obtain addresses from the DHCP server for the
inside interface.
• Firepower 4100/9300—All data inetrfaces are disabled.
• ISA 3000—All data interfaces are enabled and part of the
same bridge group, BVI1. GigabitEthernet1/1 and 1/3 are
outside interfaces, and GigabitEthernet1/2 and 1/4 are inside
interfaces. GigabitEthernet1/1 (outside1) and 1/2 (inside1),
and GigabitEthernet1/3 (outside2) and 1/4 (inside2)
(non-fiber models only) are configured as Hardware Bypass
pairs.
• All other models—The outside and inside interfaces are the
only ones configured and enabled. All other data interfaces
are disabled.
Data interface configuration.
Interface is Default.
Addressing is Explicit.
The default outside port based on the device model. See Default
Configuration Prior to Initial Setup, on page 26.
The IP address is obtained by DHCP and IPv6 autoconfiguration,
or it is a static address as entered (IPv4, IPv6, or both).
Firepower 4100/9300: Data interfaces are not pre-configured.
ISA 3000: None. You must set the BVI1 IP address manually.
Outside physical interface and
IP address.
Implied.If you configure a static IPv4 or IPv6 address for the outside
interface, a static default route is configured for IPv4/IPv6 as
appropriate, pointing to the gateway you defined for that address
type. If you select DHCP, the default route is obtained from the
DHCP server.
Network objects are also created for the gateway and the "any"
address, that is, 0.0.0.0/0 for IPv4, ::/0 for IPv6.
Static routes.
Implied.inside_zone, containing the inside interfaces. For the Firepower
4100/9300, you need to add interfaces manually to this security
zone.
outside_zone, containing the outside interfaces. For the Firepower
4100/9300, you need to add interfaces manually to this zone.
(You can edit these zones to add other interfaces, or create your
own zones.)
Security zones.
Getting Started
31
Getting Started
Configuration After Initial Setup

Cisco Firepower 1140 Specifications

General

Processor cores	16
Processor family	Intel
Built-in processor	Yes
Firewall throughput	2200 Mbit/s
IPSec VPN throughput	1.2 Gbit/s
Maximum firewall connections	400000
Maximum firewall connections per second	100000
Wi-Fi	No
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
