SSD1 Alert Status
• Off—SSD has normal activity.
• Amber—SSD failure.
8FAN
• Off—The environmental subsystem
is not active yet.
• Green—The fans are running
normally. It may take up to one
minute for the LED status to turn
green after power is on.
• Amber—One fan has failed. The
system can continue to operate
normally, but fan service is required.
• Amber, flashing—Two or more fans
have failed, or the fan tray has been
removed from the system. Immediate
attention is required.
7
Ethernet Link
• Green—The link partner is detected;
no activity.
• Green, flashing—Network activity is
detected.
10SSD2 Alert Status
• Off—SSD has normal activity.
• Amber—SSD failure.
9
Fiber Port
• Green—Port is enabled, the link
partner is detected.
• Amber—Port is enabled, but the link
partner is not detected.
• Green, flashing—Port is enabled;
network activity is detected.
12Ethernet Speed
• Green, flashing—The number of
flashes determines link speed; 1
flash=10 Mbit, 2=100 Mbit, 3=1 Gbit.
11
The following figure shows the Firepower 2130 and 2140 front panel LEDs.
Cisco Firepower 2100 Series Hardware Installation Guide
12
Overview
Front Panel LEDs
