Port 2 network activity LEDs:
• Amber—No connection, or port is not in use,
or no link or network failure.
• Green—Link up, no network activity.
• Green, flashing—Network activity.
6BP (bypass LED):
• Green—In standby mode.
• Amber, flashing—Port is in hardware bypass
mode, failure event.
5
The following table describes the cable specifications needed to keep the insertion loss as low as possible.
Table 2: 40-Gb BASE-SR Cable Specifications
Supported CableInterface
50 microns core diameterEthernet 40-G BASE-SR4
2000/4700 (OM3/4) modal bandwidth (MHz*km)850 nm wavelength
50 m cable distanceMPO-12 port adapter
See the Cisco 40GBASE QSFP Modules Data Sheet for specifications of the QSFP for the 40-Gb BASE-SR-4.
Note
We recommend the following Cisco OM3 MTP/MPO cables.
Table 3: Cisco Cables
Cable LengthCisco Part Number
5 mCAB-ETH-40G-5M
10 mCAB-ETH-40G-10M
20 mCAB-ETH-40G-20M
1-Gb SX/10-Gb SR/10-Gb LR Network Module with Hardware Bypass
The following figure shows the front panel of the 1-Gb SX, 10-Gb SR and 10-Gb LR hardware bypass network
modules (FPR4K-NM-6X1SX-F, FPR4K-NM-6X10SR-F, FPR4K-NM-6X10LR-F). This is a single-wide
module that does not support hot swapping. The six ports are numbered from top to bottom, left to right. Pair
ports 1 and 2, 3 and 4, and 5 and 6 to form hardware bypass paired sets.
Make sure you have the correct firmware package and software version installed to support this network
module. For instructions on how to verify your firmware package version and to upgrade the firmware if
necessary, see the Cisco Firepower 4100/9300 FXOS Firmware Upgrade Guide. See Cisco Firepower 4100/9300
FXOS Compatibility for the software compatibility matrix.
Note
Overview
20
Overview
1-Gb SX/10-Gb SR/10-Gb LR Network Module with Hardware Bypass
