DescriptionPINDescriptionPIN
DC Power LEDs16Management Interface7
Gigabit Ethernet LEDs17DC power connection A8
Management LED18DC power connection B9
ISA 3000 Shutdown
There is a new graceful shutdown option supported for Firepower Threat Defense as of 7.0.2/7.2. There is
also an LED change new for 7.0.5/7.3. Use shutdown when you intend to remove the device from the network,
for example to replace it, or for any scheduled maintenance.
There is no change to procedures with ASA.
It is recommended to wait for10 seconds after the System LED is switched OFF to unplug the power
from the device.
Note
After shutting down the device, you can turn it back on only by Power cycling the device. There is no hardware
On/Off switch for the device on the chassis. Power up the device to restart the device again.
LEDs
The following table describes the LEDs for the Cisco ISA 3000.
Table 1: LED Descriptions
DescriptionActivityLED
Off — No power
Green Steady on — Normal operation
Green Flashing — Boot up phase
Red Flashing — BIOS and POST
Red — System is not functioning properly.
Power StatusSystem
Off — No link (default)
Green Steady on — Port link with no activity
Green Flashing — Transmitting and Receiving data
Management Port StatusMGMT
Off — Power is not present
Green Steady on — Power is present on the associated circuit. (Hardware controlled)
Red Steady on — Power is not present on the associated circuit, and the system is
configured for dual-input power
DC Power StatusDC_A
DC_B
Product Overview
5
Product Overview
ISA 3000 Shutdown
