DescriptionActivityLED
Off — Alarm Out not configured or the system is off (Default)
Green Steady on — Alarm Out is configured, no alarm detected.
Red Steady on — Minor alarm detected
Red Flashing — Major alarm detected
Alarm monitoringAlarm Out
Off — Alarm In not configured or the system is off (Default)
Green Steady on — Alarm In is configured, no alarm detected.
Red Steady on — Minor alarm detected
Red Flashing — Major alarm detected
Alarm monitoringAlarm In
1&2
Off — No link
Green Steady on — Link is up
Green Flashing — Transmitting and Receiving data
Amber — Fault, check log
Port 1&2 and in the copper SKU, 3&4 LEDs fast blink amber together — Those two ports
are in bypass mode.
Link StatusEthernet
Ports
Off — RJ-45 is being used for console
Green — Mini USB is being used for console
Console connection
Status
Console
Memory and Storage
The Cisco ISA 3000 has the following:
• 8-GB DRAM (soldered down).
• 16-GB onboard flash memory
• 64-GB mSATA solid state drive (SSD)
• 1-GB removable SD flash memory card - industrial temp
USB Ports
The Cisco ISA 3000 has two externally accessible Type-A USB (4-pin) connectors. Each USB port will
support output powering of 5 volts and up to a maximum of 500 mA.
Management Ethernet Port
A management-only 10/100/1000 BaseT Ethernet port is provided. This port will be the only port able to be
used for booting over the network, or for initial setup and management of the system. This port is Management
1/1 in the configuration.
Product Overview
6
Product Overview
Memory and Storage
