Cisco Linksys E900 User Manual

68
Maintaining and Monitoring
Linksys E-Series
4. To view the logs, click View Log. The Log window opens.
5. Select the log you want to see from the Type drop-down list.
• Incoming Log—The source IP addresses and destination port
numbers for incoming Internet traffic
• Outgoing Log—Local IP addresses, destination URLs/IP addresses,
and service/port numbers for outgoing Internet traffic
• Security Log—Logins for the browser-based utility
• DHCP Client Log—Local DHCP server status information
6. To save the log, click Save the Log, then click OK or Save.
CAUTION
All logs that are not saved will be lost whenever the router restarts.

Cisco Linksys E900 Specifications

General

Category	Wireless Router
Frequency Band	2.4 GHz
Wireless Speed	Up to 300 Mbps
Ethernet Ports	4 x 10/100 Mbps LAN, 1 x 10/100 Mbps WAN
Security	WEP, WPA, WPA2
Antennas	2 Internal
Weight	0.6 lbs (0.27 kg)
Model	Linksys E900
Wireless Standards	IEEE 802.11n
