Cisco Linksys RE1000 Getting Started

4
Getting Started
RE1000 Range Extender
4. Select the network to use, then click Next.
5. Type your network’s password, then click OK.
- OR -
If your network is hidden (your router does not broadcast its name), click
My network is hidden, enter your network’s information, then click OK.
6. Click Next. Your extender is set up, and you are prompted to move the
extender to its final location.
TIP
For best performance, position the extender where the wireless
signal of your router or access point is reliably strong (at least 60%
strength).

Cisco Linksys RE1000 Specifications

General

Wireless Standard	802.11n
Wireless Speed	Up to 300 Mbps
Frequency Band	2.4 GHz
Ethernet Ports	1 x 10/100 Mbps
Security Features	WEP, WPA, WPA2
Antennas	2 internal
Operating Humidity	10% to 85% Non-condensing
Storage Humidity	5% to 90% Non-condensing
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
