37
Chapter 5: Configuring the Wireless-G Broadband Router
The Administration Tab - Diagnostics
Wireless-G Broadband Router with SRX400
The Administration Tab - Diagnostics
The diagnostic tests (Ping and Traceroute) allow you to check the connections of your network components.
Ping Test
Ping Parameters
Ping Target IP or Domain Name, No. of Pings, and Packets Sent. The Ping test will check the status of a
connection. To start the test, enter the IP address or domain name of the PC whose connection you wish to test,
how many times you wish to test it, and the size of the packet for testing. Then, click the Start Test button. The
test field will show if the test was successful. To stop the test, click the Abort Test button. Click the Clear button
to clear the field.
Traceroute Test
Traceroute Parameters
IP Address or Domain Name. To test the performance of a connection, enter the IP address or domain name of
the PC whose connection you wish to test and click the Start Test button. The test field will show if the test was
successful. To stop the test, click the Abort Test button. Click the Clear button to clear the screen.
Figure 5-37: Administration Tab - Diagnostics
