Cisco MCU24 - Chapter 4 Cisco Unified Videoconferencing 3515 MCU Cable Connections and Pin-Outs; Unit RS-232 9-Pin Serial Port on the 3515 MCU

CHAPTER
4-1
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU12 and MCU24 Release 5.1
OL-11897-01
4
Cisco Unified Videoconferencing 3515 MCU
Cable Connections and Pin-outs
This section describes the following topics:
• Unit RS-232 9-Pin Serial Port on the 3515 MCU, page 4-1
• RJ-45 8-Pin IP Network Port on the 3515 MCU, page 4-2
Unit RS-232 9-Pin Serial Port on the 3515 MCU
Table 4-1 describes the Cisco Unified Videoconferencing 3515 MCU unit RS-232 9-pin D-type serial
port pin-out configuration.
Table 4-1 RS-232 9-pin D-Type Serial Port Pin-out
Pin Function I/O
1NC
2 RXD Input
3 TXD Output
4NC
5GND
6NC
7NC
8NC
9NC
