RJ-45 8-Pin IP Network Port on the 3515 MCU
RJ-45 8-Pin IP Network Port on the 3515 MCU
Table 4-2 describes the pin-out configuration of the RJ-45 IP network port.
Table 4-2 Pin-out Configuration of the RJ-45 IP Network Port
Pin Function I/O
1 TXD+ Output
2 TXD+ Output
3 RXD+ Input
4NC
5NC
6 RXD- Input
7NC
8NC
