22-14
Cisco MDS 9000 Family Troubleshooting Guide, Release 3.x
OL-9285-05
Chapter 22 Troubleshooting IPsec
IPsec Issues
Source port no 0 mask:0x0
Dest port no 0 mask:0x0
Hard limit 483183820800 bytes
Soft limit 420369924096 bytes
SA byte count 873056 bytes <----Elapsed traffic
SA user byte count 873056 bytes <----Elapsed traffic
Error count:auth:0, pad:0, replay:0
Packet count 7137
Hard limit expiry 1100652419 secs (since January 1, 1970), remaining 214 1 secs
Soft limit expiry 1100652394 secs (since January 1, 1970), remaining 211 6 secs
Sequence number:7138
Antireplay window:0xffffffff.0xffffffff.0xffffffff.0xffffffff
MDSA# show ipsec internal crypto-accelerator interface gigabitethernet 7/1 sad outbound 1
Outbound SA 1 :
SPI 136487426 (0x822a202), MTU 1400, MTU_delta 4
Mode :Tunnel, flags:0x92100000000000
IPsec mode is ESP
Tunnel options index:0, ttl:0x40, flags:0x1
Encrypt algorithm is DES/3DES
Auth algorithm is MD5
Tunnel source ip address 10.10.100.231
Tunnel destination ip address 10.10.100.232
Hard limit 483183820800 bytes
Soft limit 376883380224 bytes
SA byte count 874544 bytes <----Elapsed traffic
SA user byte count 874544 bytes <----Elapsed traffic
Packet count 7150
Hard limit expiry 1100652419 secs (since January 1, 1970), remaining 208 9 secs
Soft limit expiry 1100652384 secs (since January 1, 1970), remaining 205 4 secs
Outbound MAC table index:1
Sequence number:7151
MDSC# show ipsec internal crypto-accelerator interface gigabitethernet 1/2 sad outbound
513
Outbound SA 513 :
SPI 940863490 (0x38147002), MTU 1400, MTU_delta 4
Mode :Tunnel, flags:0x92100000000000
IPsec mode is ESP
Tunnel options index:0, ttl:0x40, flags:0x1
Encrypt algorithm is DES/3DES
Auth algorithm is MD5
Tunnel source ip address 10.10.100.232
Tunnel destination ip address 10.10.100.231
Hard limit 483183820800 bytes
Soft limit 449360953344 bytes
SA byte count 855648 bytes <----Elapsed traffic
SA user byte count 855648 bytes <----Elapsed traffic
Packet count 7122
Hard limit expiry 1100652419 secs (since January 1, 1970), remaining 206 4 secs
Soft limit expiry 1100652397 secs (since January 1, 1970), remaining 204 2 secs
Outbound MAC table index:125
Sequence number:7123
