Cisco Meraki MX67 User Manual

MX68/MX68W/MX68CW Side Panel Functions
Additional functions on the side panel are described below, from left to right.
SIM Card Slot (MX68CW)
Active, supported SIM cards can be inserted into this
slot to enable cellular capabilities.
USB port
USB 2.0 for 3G/4G wireless cards. Traffic status is
indicated by the USB LED.
Bottom Panel
Please note that the serial number is located on the product label at the bottom panel of MX67/MX68 devices
10

Cisco Meraki MX67 Specifications

General

Model	MX67
Category	Security System
Firewall Throughput	450 Mbps
VPN Throughput	200 Mbps
Advanced Security Throughput	250 Mbps
Maximum VPN Tunnels	50
Recommended Clients	50
LAN Interfaces	4 x GbE
802.11ac Wave 2	No
USB Interface	1 x USB 2.0
Power over Ethernet (PoE)	No
Operating Temperature	32°F to 104°F (0°C to 40°C)
WAN Interfaces	2 x GbE
Operating Humidity	5 to 95% non-condensing
