In-Room Control on Touch10
for Cisco TelePresence
MX200 G2, MX300 G2,
MX700, MX800,
SX10, SX20, SX80
Collaboration Endpoint
software version CE8.2
D15358.02 - JULY 2016
www.cisco.com
© 2016 Cisco Systems, Inc.
All rights reserved.
22
Events
Pressed Triggered when the slider is pressed
Value: N/A
Changed Triggered when the slider is moved while holding down,
and when the slider is released
Value: 0-255
Released Triggered when the slider is released
Value: 0-255
Commands
The visual appearance of the slider changes immediately when you
tap or slide it. However, the control system must always send a
SetValue
command to the video system to tell the new position of
the slider. This ensures that the status is updated accordingly.
Slider
Example of use: Dimmable lights, volume control.
A slider selects values within a set range. The minimum value is
represented by 0, and the maximum value is represented by 255.
When the slider is being pressed and moved, events are sent
maximum 5 times a second.
When you tap the bar, the slider is immediately moved to that new
position.
Example: Set the slider with WidgetId = "slider" to position "98".
xCommand UserInterface Extensions Widget SetValue WidgetId: "slider"
Value: "98"
Example: Press the slider with WidgetId = "slider", and move it into a
new position ("68"), and release.
Terminal mode
*e UserInterface Extensions Event Pressed Signal: "slider"
** end
*e UserInterface Extensions Event Changed Signal: "slider:32"
** end
*e UserInterface Extensions Event Changed Signal: "slider:68"
** end
*e UserInterface Extensions Event Released Signal: "slider:68"
** end
XML mode
.
.
.
<Event>
<UserInterface item="1">
<Extensions item="1">
<Widget ite m ="1">
<Action ite m="1">
<WidgetId item="1">slider</WidgetId>
<Value item="1">68</Value>
<Type item="1">released</Type>
</Action>
</Widget>
</Extensions>
</UserInterface>
</Event>
