12 40/100-Gigabit
QSFP28 ports
3Beacon (BCN), Status
(STS), and Environment
(ENV) LEDs
1
96 10-/25-Gigabit SFP28
ports
2
To determine which transceivers, adapters, and cables are support this switch, see the Cisco Transceiver
Modules Compatibility Information document.
The following figure shows the switch features on the power supply side of the chassis.
Console port (1)5Fan modules (3) with slots
numbered from 1 (left) to
3 (right)
1
Grounding pad6Management port
(1—SFP optical port)
2
Power supply modules (1
or 2) (AC power supplies
shown) with slots
numbered 1 (top) and 2
(bottom)
7USB port (1)3
Management port
(1—RJ-45 copper port)
4
The following figure shows the side of the chassis.
Cisco Nexus 93360YC-FX2 NX-OS Mode Switch Hardware Installation Guide
3
