Cisco NCS 1014 User Manual

Online insertion and removal (OIR) duration for the fan module at 30℃ ambient temperature is five minutes.
Caution
Step 1 Push and hold the spring-loaded lever toward the left with your thumb (unlock position).
Figure 5: Spring-Loaded Lever in Holding or Unlock Position
Sping-loaded lever1
Step 2 Holding the handle with one hand and supporting the fan module with the other hand, gently pull it out of the chassis.
Remove and Replace Cisco NCS 1014 Modules
7
Remove and Replace Cisco NCS 1014 Modules
Remove and Replace the Fan Module
