1-13
Cisco Nexus 1000V for Microsoft Hyper-V Installation Guide, Release 5.2(1)SM1(5.2)
OL-30997-01
Chapter 1 Installing the Cisco Nexus 1000V for Microsoft Hyper-V
Installing the VSM Software
Step 9 Create a VLAN inside the Network Segment using the command switchport access vlan <number>,
for example, switchport access vlan 100.
Step 10 Associate the Network Segment Pool to the Network Segment using the command member-of network
segment pool <name>, for example, member-of network segment pool IntranetSJ.
Step 11 Import the IP pool template to the Network Segment using the command ip pool import template
<name>, for example, ip pool import template pool10.
Step 12 Publish the Network Segment using the command publish network segment <name>, for example,
publish network segment VMNetworkA. Type exit.
Step 13 Create a virtual Ethernet port profile of type vethernet using the command port-profile type vethernet
<name>, for example, port-profile type vethernet Veth-policy.
Step 14 Enter the no shutdown command to keep the system in a power-on state. Enter state enabled at the
prompt.
Step 15 Publish the port profile using the command publish port-profile and type exit. The port profile is
imported for publishing the Network uplink.
Step 16 Create a virtual Ethernet port profile of type ethernet using the command port-profile type ethernet
<name>, for example, port-profile type ethernet UplinkNoPortChannel.
Step 17 Enter the no shutdown command to keep the system in a power-on state. Enter state enabled at the
prompt.
Step 18 Create a Network Uplink using the command nsm network uplink NexusUplink.
Step 19 Associate the Network Segment Pool using the command allow network segment pool IntranetSJ, for
example, allow network segment pool IntranetSJ.
Step 20 Import the port profile that was created earlier using the command import port-profile <name>, for
example, import port-profile eth-pp-policy.
Step 21 Publish the Network Uplink using the command publish network uplink <name>, for example,
publish network uplink NexusUplink. Type exit.
Step 22 Copy the running configuration to the start-up configuration using the copy running-config
startup-config command. The following message is displayed in the window: Copy complete, now
saving to disk (please wait)
Step 23 Enter the show running-config command to verify the configuration.
Note The setup script configures the VSM to function in L3 control mode. L2 control mode is not supported
with Cisco Nexus 1000V for Microsoft Hyper-V. When configuring L3 control with Microsoft Hyper-V,
you do not need to create a port profile with capability L3control. The VSM communicates with the
Microsoft Server 2012 management interface directly. There is no need to create a special vEthernet port
profile to be assigned to the Windows 2012 host.
Configuring the SCVMM Fabric Workflow
Note The entire workflow to configure the SCVMM Fabric Workflow can also be performed using scripts. For
more information, see the
“PowerShell Scripts for Configuring the SCVMM Fabric Workflow” section
on page 1-19.
