Efficient Transceiver and Cabling Options
The Cisco Nexus 5500 platform supports a wide variety of 1 and 10 Gigabit Ethernet connectivity options using
Cisco 10GBASE SFP+ modules.
In addition, the Cisco Nexus 5500 platform supports 1 Gigabit Ethernet connectivity options using 1GBASE SFP
modules, 8/4/2 -Gbps Fibre Channel SFP+ and 4/2/1-Gbps Fibre Channel SFP interfaces are supported with
expansion module options.
Table 2 lists the supported transceiver options.
Table 2. Cisco Nexus 5500 Platform Transceiver Support Matrix
Cisco SFP Description
FET-10G 10-Gbps SFP+ module for Cisco Nexus 2000 Series to Cisco Nexus 5000 Series connectivity
Cisco SFP-10G-SR 10GBASE-SR SFP+ module (multimode fiber [MMF])
Cisco SFP-10G-LR 10GBASE-LR SFP+ module (single-mode fiber [SMF])
Cisco SFP-10G-ER 10GBASE-ER-SFP+ module (single-mode fiber[SMF])
Cisco SFP-H10GB-CU1M 10GBASE-CU SFP+ cable 1m (Twinax cable)
Cisco SFP-H10GB-CU3M 10GBASE-CU SFP+ cable 3m (Twinax cable)
Cisco SFP-H10GB-CU5M 10GBASE-CU SFP+ cable 5m (Twinax cable)
Cisco SFP-H10GB-ACU7M 10GBASE-CU SFP+ cable 7m (active Twinax cable)
Cisco SFP-H10GB-ACU10M 10GBASE-CU SFP+ cable 10m (active Twinax cable)
Cisco GLC-T 1000BASE-T SFP
GLC-ZX-SM 1000BASE-ZX SFP transceiver module for SMF, 1550-nm wavelength, dual LC/PC connector
Cisco GLC-SX-MM Gigabit Ethernet SFP, LC connector SX transceiver (MMF)
Cisco GLC-SX-MMD Gigabit Ethernet SFP, LC connector SX transceiver (MMF), extended temperature range and digital optical
monitoring (DOM)
Cisco GLC-LH-SM Gigabit Ethernet SFP, LC connector LX/LH transceiver (SMF)
Cisco GLC-LH-SMD Gigabit Ethernet SFP, LC connector LX/LH transceiver (SMF), extended temperature range and digital optical
monitoring (DOM)
Cisco SFP-GE-T 1000BASE-T SFP, extended temperature range
Cisco SFP-GE-S Gigabit Ethernet SFP, LC connector SX transceiver (MMF), extended temperature range and digital optical
monitoring (DOM)
Cisco SFP-GE-L Gigabit Ethernet SFP, LC connector LX/LH transceiver (SMF), extended temperature range and DOM
Cisco DS-SFP-FC4G-SW 4-Gbps Fibre Channel SW SFP, LC (for Fibre Channel expansion module ports)
Cisco DS-SFP-FC4G-LW 4-Gbps Fibre Channel LW SFP, LC (for Fibre Channel expansion module ports)
Cisco DS-SFP-FC8G-SW 8-Gbps Fibre Channel SW SFP+, LC (for Fibre Channel expansion module ports)
Cisco DS-SFP-FC8G-LW 8-Gbps Fibre Channel LW SFP+, LC (for Fibre Channel expansion module ports)
