Chapter 2 Alarm Troubleshooting
Alarm Logical Objects
Alarm profile list objects are defined in Table 2-7.
Note Alarm logical object names can appear as abbreviated versions of standard terms used in the system and
the documentation. For example, the “STM” logical object refers to the STM-N signal. Logical object
names or industry-standard terms are used within the entries as appropriate.
Table 2-7 Alarm Logical Object Type Definitions
Type Definition
BITS
Building integrated timing supply (BITS) incoming references (BITS-1, BITS-2).
BPLANE
The backplane.
CE100T
The CE-100T-8 Ethernet card.
CEMR
The CE-MR-6 Ethernet card.
E1
A E1 port on the 15310-MA SDH CTX, E1-21/DS3-E3-3, or E1-63/DS3-E3-3
card.
DS3
A DS-3 port on the 15310-MA SDH CTX, E1-21/DS3-E3-3, or E1-63/DS3-E3-3
card.
E3
A E3 port on the 15310-MA SDH CTX, E1-21/DS3-E3-3, or E1-63/DS3-E3-3
card.
ENVALRM
An environmental alarm port.
EQPT
A card, its physical objects, and logical objects as they are located in any of the
noncommon card slots. The EQPT object is used for alarms that refer to the
card itself and all other objects on the card including ports, lines, and VC (virtual
container).
EXT-SREF
BITS outgoing references (SYNC-BITS1, SYNC-BITS2).
FAN
Fan located in the ONS 15310-MA SDH shelf.
FUDC
SDH F1 byte user data channel for an ONS 15310-MA SDH ML-100T-8 Ethernet
card.
ML100T
The ML-100T-8 Ethernet card.
NE
The entire network element.
NE-SREF
The timing status of the NE.
STM
An STM1 port or STM1, STM4 and STM16 port on the ONS 15310-MA SDH.
PPM
Pluggable port module (PPM, also called SFP).
RPRIF
Interface for Resilient Packet Ring technology as defined in IEEE 802.17b. Also
called RPR-IEEE.
PWR
The node power supply.
SHELF
The ONS 15310-MA SDH shelf.
VCMON-HP
VC alarm detection at the monitor point (upstream from the cross-connect).
Note The network element reports alarms or conditions on ingress ports of the
card. Alarms detected at the internal ports (TERM side) will be ingress
mapped to the MON side. The alarm profile entities of VCMON-HP, if
available, should be changed to the same severity as the customized
severity for a specific VCMON-HP alarm.
