Chapter 2 Alarm Troubleshooting
Alarm Logical Objects
2.3 Alarm Logical Objects
The CTC alarm profile list organizes all alarms and conditions according to the logical objects they are
raised against. These logical objects represent physical objects such as cards, logical objects such as
circuits, or transport and signal monitoring entities such as the SDH overhead bits. One alarm can appear
in multiple entries. It can be raised against multiple objects. For example, the loss of signal (LOS) alarm
can be raised against the optical signal (STM-N) or the optical transport layer overhead (OTN) as well
as other objects. Therefore, both STM: LOS and OTN: LOS appear in the list (as well as the other
objects).
FANDEGRADE (FAN) MANSWTOPRI (EXT-SREF) HP-RFI (VCTRM-HP)
FE-AIS (DS3) MANSWTOPRI (NE-SREF) LP-RFI (VCMON-LP)
FE-DS3-NSA (DS3) MANSWTOSEC (EXT-SREF) LP-RFI (VCTRM-LP)
FE-DS3-SA (DS3) MANSWTOSEC (NE-SREF) ROLL (VCMON-HP)
FE-EQPT-NSA (DS3) MANSWTOTHIRD (EXT-SREF) TPTFAIL (CEMR)
FE-FRCDWKSWBK-SPAN (STM) MANSWTOTHIRD (NE-SREF) TPTFAIL (ML100T)
FE-FRCDWKSWPR-SPAN (STM) MANUAL-REQ-SPAN (STM) TX-AIS (E1)
FE-IDLE (DS3) MATECLK (EQPT) TX-AIS (DS3)
FE-LOCKOUTOFPR-SPAN (STM) MEA (EQPT) TX-IDLE (E1)
FE-LOF (DS3) MEA (FAN) TX-LOF (E1)
FE-LOS (DS3) MEA (PPM) TX-RAI (E1)
FE-MANWKSWBK-SPAN (STM) MEA (SHELF) TX-RAI (DS3)
FE-MANWKSWPR-SPAN (STM) MEM-GONE (EQPT) HP-UNEQ (VCMON-HP)
FEPRLF (STM) MEM-LOW (EQPT) HP-UNEQ (VCTRM-HP)
FORCED-REQ (VCMON-HP) MFGMEM (BPLANE) LP-UNEQ (VCMON-LP)
FORCED-REQ (VCMON-LP) MFGMEM (FAN) LP-UNEQ (VCTRM-LP)
FORCED-REQ-SPAN (STM) MFGMEM (PPM) UNQUAL-PPM (PPM)
FP-LINK-LOSS (EQPT) NO-CONFIG (EQPT) VCG-DEG (VCG)
FRCDSWTOINT (NE-SREF) NON-CISCO-PPM (PPM) VCG-DOWN (VCG)
FRCDSWTOPRI (EXT-SREF) OOU-TPT (VCTRM-HP) WKSWPR (EQPT)
FRCDSWTOPRI (NE-SREF) OOU-TPT (VCTRM-LP) WKSWPR (STM)
FRCDSWTOSEC (EXT-SREF) OPEN-SLOT (EQPT) WKSWPR (VCMON-HP)
FRCDSWTOSEC (NE-SREF) LP-PLM (VCMON-HP) WKSWPR (VCMON-LP)
FRCDSWTOTHIRD (EXT-SREF) LP-PLM (VCTRM-HP) WTR (EQPT)
FRCDSWTOTHIRD (NE-SREF) HP-PLM (VCMON-LP) WTR (STM)
FRNGSYNC (NE-SREF) HP-PLM (VCTRM-LP) WTR (VCMON-HP)
FSTSYNC (NE-SREF) PORT-MISMATCH (CEMR) WTR (VCMON-LP)
LPBKTERMINAL (E3) PRC-DUPID (STM) —
LPBKTERMINAL (STM) PROTNA (EQPT) —
Table 2-6 ONS 15310-MA SDH Alarm and Condition Alphabetical List (continued)
