2-18
Cisco ONS 15454 Procedure Guide, R8.0
78-17697-01
Chapter 2 Install Cards and Fiber-Optic Cable
NTP- A247 Install Fiber-Optic Cables
OC192 IR/STM64 SH 1550 –1 dBm +2 dBm –14 dBm –1 dBm
OC192 LR/STM64 LH 1550 +7 dBm +10 dBm –19 dBm –10 dBm
OC192 LR/STM64 LH ITU 15xx.xx +3 dBm +6 dBm –22 dBm –9 dBm
MRC-2.5G-4 –10 dBm –3 dBm –18 dBm –3 dBm
15454_MRC-12 (ONS-SI-2G-S1) –10 dBm –3 dBm –18 dBm –3 dBm
15454_MRC-12 (ONS-SI-2G-I1) –5 dBm 0 dBm –18 dBm 0 dBm
15454_MRC-12 (ONS-SI-2G-L1) –2 dBm 3 dBm –27 dBm –9 dBm
15454_MRC-12 (ONS-SI-2G-L2) –2 dBm 3 dBm –28 dBm –9 dBm
15454_MRC-12 (ONS-SC-2G-30.3
through ONS-SC-2G-60.6)
0 dBm 4 dBm –28 dBm –9 dBm
15454_MRC-12 (ONS-SI-622-I1) –15 dBm –8 dBm –28 dBm –8 dBm
15454_MRC-12 (ONS-SI-622-L1) –3 dBm 2 dBm –28 dBm –8 dBm
15454_MRC-12 (ONS-SI-622-L2) –3 dBm 2 dBm –28 dBm –8 dBm
15454_MRC-12
(ONS-SE-622-1470 through
ONS-SE-622-1610)
0 dBm 5 dBm –28 dBm –3 dBm
15454_MRC-12 (ONS-SI-155-I1) –15 dBm –8 dBm –30 dBm –8 dBm
15454_MRC-12 (ONS-SI-155-L1) –5 dBm 0 dBm –34 dBm –10 dBm
15454_MRC-12 (ONS-SI-155-L2) –5 dBm 0 dBm –34 dBm –10 dBm
15454_MRC-12
(ONS_SE-155-1470 through
ONS-SE-155-1610)
0 dBm 5 dBm –34 dBm –3 dBm
15454_MRC_12
ONS-SI-155-I1-MM=
–9 dBm –14 dBm –14 dBm –5 dBm
15454_MRC_12
ONS-SI-622-I1-MM=
–9 dBm –14 dBm –14 dBm –5 dBm
15454_MRC_12
ONS-SC-Z3-1470 through
ONS-SC-Z3-1610
0 dBm 5 dBm –9 dBm –5 dBm
15454_MRC_12
ONS-SE-Z1=
–5 dBm 0 dBm –10 dBm
0 dBm
–18 dBm
0 dBm
0 dBm
–23 dBm (OC-3)
–23 dBm (OC-12)
0 dBm (OC-48)
–21 dBm (FC)
–22 dBm (GE)
OC192SR1/STM64IO Short Reach
(ONS-XC-10G-S1)
–6 dBm –1 dBm –11 dBm –1 dBm
OC192/STM64 Any Reach
(ONS-XC-10G-S1)
–6 dBm –1 dBm –11 dBm –1 dBm
Table 2-5 Optical Card Transmit and Receive Levels (continued)
Card
Transmit Receive
Minimum Maximum Minimum Maximum
