2-19
Cisco ONS 15454 Procedure Guide, R8.0
78-17697-01
Chapter 2 Install Cards and Fiber-Optic Cable
NTP- A245 Route Fiber-Optic Cables
Step 2 As needed, complete the “DLP-A207 Install Fiber-Optic Cables on the LGX Interface” task on
page 19-5.
Step 3 As needed, complete the “DLP-A428 Install Fiber-Optic Cables in a 1+1 Configuration” task on
page 21-8.
Step 4 As needed, complete the “DLP-A43 Install Fiber-Optic Cables for Path Protection Configurations” task
on page 17-44.
Step 5 As needed, complete the “DLP-A44 Install Fiber-Optic Cables for BLSR Configurations” task on
page 17-47.
Step 6 Continue with the “NTP-A245 Route Fiber-Optic Cables” procedure on page 2-19.
Stop. You have completed this procedure.
NTP-A245 Route Fiber-Optic Cables
Step 1 As needed, complete the “DLP-A45 Install the Fiber Boot” task on page 17-49. Fiber boots are required
for all OC-N cards except the OC-192,OC192SR1/STM64IO Short Reach and OC192/STM64 Any
Reach (OC192-XFP), and OC-48 AS cards.
Step 2 Open the fold-down front door on the cable-management tray.
Step 3 Route the fiber-optic cable on the card faceplate through the fiber clip on the faceplate, if provided.
Step 4 If you installed a 15454_MRC-12 card, complete the “DLP-A443 Install the Fiber Clip on
15454_MRC-12 Cards” task on page 21-25. Fiber clips are factory-attached to the faceplate of optical
cards except the 15454_MRC-12 cards. The 15454_MRC-12 cards are shipped with two versions of a
fiber clip that plug into the faceplate.
Step 5 Route the fiber-optic cables into the cable-management tray.
OC192/STM64 Any Reach
(ONS-XC-10G-I2)
–1 dBm 2 dBm –14 dBm 2 dBm
OC192/STM64 Any Reach
(ONS-XC-10G-L2)
0 dBm 4 dBm –24 dBm –7dBm
Table 2-5 Optical Card Transmit and Receive Levels (continued)
Card
Transmit Receive
Minimum Maximum Minimum Maximum
Purpose This procedure describes how to route fiber-optic cables away from the
ONS 15454 shelf, including installing fiber boots and fiber clips.
Tools/Equipment None
Prerequisite Procedures NTP-A247 Install Fiber-Optic Cables, page 2-16
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
To Next Page
