Data Sheet
© 2008 Cisco Systems, Inc. All rights reserved. This document is Cisco Public Information. Page 4 of 5
Security
●
Password-protected system reset to factory default
●
Password-protected administrator and user access authority
●
Provisioning/configuration/authentication:
●
HTTPS with factory-installed client certificate
●
HTTP digest - encrypted authentication via MD5 (RFC 1321)
●
Up to 256-bit Advanced Encryption Standard (AES) encryption
Provisioning, administration,
and maintenance
●
Web browser administration and configuration via integral web server
●
Telephone keypad configuration with interactive voice prompts
●
Automated provisioning and upgrade via HTTPS, HTTP, Trivial File Transfer Protocol
(TFTP)
●
Asynchronous notification of upgrade availability via NOTIFY
●
Nonintrusive, in-service upgrades
●
Report generation and event logging
●
Stats in BYE message
●
Syslog and debug server records - per-line configurable web browser
Physical interfaces
●
One 10BASE-T RJ-45 Ethernet port (IEEE 802.3)
●
2 RJ-11 FXS phone ports - for analog circuit telephone device (tip/ring)
Subscriber line interface
circuit (SLIC)
●
Ring voltage: 40–55 volts root mean square (Vrms) configurable *
●
Ring frequency: 10–40 Hz *
●
Ring waveform: trapezoidal and sinusoidal *
●
Maximum ringer load: 3 ringer equivalence numbers (RENs)
●
On-hook/off-hook characteristics:
◦
On-hook voltage (tip/ring): -50V nominal
◦
Off-hook current: 25 mA min
◦
Terminating impedance: 8 configurable settings, including North America 600 ohms,
European CTR21
Regulatory compliance FCC (Part 15, Class B), cUL, CE, IC-003, A-Tick
Power supply
●
DC input voltage: +5V DC at 2.0A max.
●
Power consumption: 5W
●
Switching type (100–240V) automatic
●
Power adapter: 100–240V - 50–60 Hz (26–34 VA) AC input, 1.8 m cord
Indicator lights/LED Phone1, Phone2, Internet, Power
Documentation
●
Quick-start installation and configuration guide
●
User guide
●
Administration guide - service providers only
●
Provisioning guide - service providers only
Environmental
Dimensions
W x H x D
3.98 x 3.98 x 1.10 in.
(101 x 101 x 28 mm)
Unit weight 5.40 oz (153 g)
Operating temp. 32º to 113ºF (0º to 45ºC)
Storage temp. -77º to 158ºF (-25º to 70ºC)
Operating humidity 10% to 90% noncondensing
Storage humidity 10% to 90% noncondensing
Package Contents
●
Cisco PAP2T Internet Phone Adapter with 2 VoIP Ports
●
Power adapter
●
RJ-45 Ethernet cable
●
Quick installation guide
Product Warranty
1-year limited hardware warranty with return to factory replacement and 90-day limited software warranty
