CHAPTER
2-1
Cisco PIX Security Appliance Hardware Installation Guide
78-15170-03
2
PIX 501
This chapter describes how to install the PIX 501, and includes the following sections:
• PIX 501 Product Overview, page 2-1
• Installing the PIX 501, page 2-3
• Connecting a Power Supply Module to the PIX 501, page 2-3
• Removing and Replacing the PIX 501 Chassis Cover, page 2-4
• Replacing a Lithium Battery, page 2-6
Note The PIX 501 is not supported in software Version 7.0(1).
PIX 501 Product Overview
This section describes the PIX 501 front and rear panels and the panel LEDs.
Figure 2-1 shows the front view of the PIX 501.
Figure 2-1 PIX 501 Front Panel
67848
POWER
VPN TUNNEL
LINK/ACT
100 MBPS
1234
CISCO
PIX
®
501
FIREWALL
