4 RV0xx Series Routers Quick Start Guide
Status Lights
1-4 (RV042 and
RV042G) or 1-8
(RV082 and RV016)
Use these numbered ports to connect computers
and other local network devices.
9-13 and 3-7 Dual
Function Ports
(RV016)
Use these numbered ports as LAN ports
(numbered 9-13) or configure them for use as
Internet ports (numbered 3-7). The status is
shown on the corresponding status lights: LAN/
Act 9-13 or Internet/Act 3-7.
Light Description
DIAG Lit—The router is preparing for use. Unlit—The
router is ready for use.
System Steady—The router is powered on. Flashing—
The router is running a diagnostic test.
Internet (RV082,
RV042, RV042G) or
Internet 1-2 (RV016)
Steady—A device is connected to the Internet
port. Flashing—There is network activity over
the Internet port.
DMZ/Internet
(RV082, RV042,
RV042G) or DMZ
(RV016)
Steady—A device is connected to the DMZ/
Internet or DMZ port. Flashing—There is network
activity over the port.
DMZ Mode (RV082,
RV042, RV042G)
Lit—The DMZ/Internet port is configured as a
DMZ. Unlit—The DMZ/Internet port is configured
as a secondary Internet connection.
1-4, 1-8 Steady—A device is connected to the numbered
LAN port. Flashing—There is network activity
over the numbered port.
RV042G Gigabit
Ports
For the Internet, DMZ/Internet, and numbered
ports, the color indicates the speed. Green—
Gigabit. Amber—10/100M.
RV016 Dual-Function Ports:
LAN/Act 9-13 Lit if the port is configured as a LAN port.
Steady—A device is connected to the port.
Flashing—There is network activity over the
port.
Internet/Act 3-7
(RV016)
Lit if the port is configured as an Internet port.
Steady—A device is connected to the port.
Flashing—There is network activity over the
port.
Port Description
