Quality of Service
QoS Advanced Mode
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 372
20
Policy Table
The Policy Table Map page displays the list of advanced QoS polices defined in the system.
The page also allows you to create and delete polices. Only those policies that are bound to an
interface are active (see Policy Binding page).
Each policy consists of:
• One or more class maps of ACLs which define the traffic flows in the policy.
• One or more aggregates that applies the QoS to the traffic flows in the policy.
After a policy has been added, class maps can be added by using the Policy Table page.
To add a QoS policy:
STEP 1 Click Quality of Service > QoS Advanced Mode > Policy Table.
This page displays the list of defined policies.
STEP 2 Click Policy Class Map Table to display the Policy Class Maps page.
-or
Click Add to open the Add Policy Table page.
STEP 3 Enter the name of the new policy in the New Policy Name field.
STEP 4 Click Apply. The QoS policy profile is added, and the Running Configuration file is updated.
Policy Class Maps
One or more class maps can be added to a policy. A class map defines the type of packets that
are considered to belong to the same traffic flow.
To add a class map to a policy:
STEP 1 Click Quality of Service > QoS Advanced Mode > Policy Class Maps.
STEP 2 Select a policy in the Filter, and click Go. All class maps in that policy are displayed.
STEP 3 To add a new class map, click Add.
STEP 4 Enter the parameters.
• Policy Name—Displays the policy to which the class map is being added.
