5
Note The Console port is above the AUX port.
Items Included with Cisco VG224 Voice Gateway
The following are included with the Cisco VG224:
• Rack-mount brackets for 19-inch rack; grounding lug and fasteners; power cord
• Chassis guard for wall-mounting applications
• Connected RJ-45-to-DB9 cable (labeled Console)
• Connected RJ-45-to-DB-25 cable (labeled Auxiliary)
• Cisco VG224 Voice Gateway Quick Start Guide (this document)
Note Power cords vary, depending upon local requirements.
Items Not Included
You may need one or more items in this list for your application:
• Four telco machine screws, for installing the chassis in a rack (Use the screw size required by the rack.)
• Eight wood screws or other fasteners, for installing the chassis on a wall. An additional starter screw is used to facilitate
wall mounting.
• PC running terminal emulation software for administrative access
• Modem for remote access
• Fast Ethernet RJ-45-to-RJ-45 straight-through cable
• Analog voice RJ-21 cable
• Tools: number 2 Phillips screwdriver; medium blade screwdriver; ESD-preventive wrist strap
4 Product Serial Number Location
The serial number label for the Cisco VG224 Voice Gateway is located on the bottom of the chassis, near the compliance label.
The size of the serial number label is 0.25 x 1 inch. It has the letters “SN:” followed by eleven characters.
5 Installing the Chassis
Safety Information
Caution For safety information you need to know before working on your Cisco VG224, see the Cisco VG224 Regulatory
Compliance and Safety Information document that accompanied this product. That document provides
translations for each of the warnings.
IMPORTANT SAFETY INSTRUCTIONS
Warning
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any
equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for
preventing accidents. To see translations of the warnings that appear in this publication, refer to the translated
