Cisco SPA100 Series Administration Guide

Getting Started
Product Features
Cisco SPA100Series Administration Guide 12
1
Product Features
Top Panel
Back Panel
Feature Description
Phone 1
Phone 2
Steady green—On hook.
Slow flashing green—Off hook.
Off—Port not ready.
Internet
Flashing green—Transmitting or receiving data through
the WAN port.
Off—No link.
System
Steady green—System ready, IP address acquired.
Slow flashing green—Acquiring IP address. (By default,
uses DHCP.)
Fast flashing green—Upgrading firmware.
Off—No power or system can not boot up.
Feature Description
Reset
Using a paperclip or similar object, press this button
briefly to restart the unit. Press and hold for 10
seconds to restore the factory default settings.
Phone 1,
Phone 2
(Gray)
Connect to an analog phone, using an RJ-11 phone
cable.
Ethernet
(Yellow)
SPA122 Only
Can be used to connect to a device on your network,
such as a computer, using an Ethernet cable.

Cisco SPA100 Series Specifications

General

Brand	Cisco
Model	SPA100 Series
Category	Adapter
Language	English
