Downstream Protect Cards
Figure 10: Downstream Protect Card Faceplate
Five downstream ports3Captive screws1
—
LEDs2
On the Cisco CMTS side of the Cisco UBR-RFSW-ADV there is only one downstream protect card.
For information about the PIDs for the downstream protect card, see Cisco UBR-RFSW-ADV Components
Part Numbers and Product Identifiers.
