State DescriptionColor/StateLED
Card is not powered on.OffPower/System
Card is either powering on and is in the process of configuring the
system, or the Cisco UBR-RFSW-ADV is in the process of downloading
and reconfiguring the system.
Green (blinking)
Normal operation.Green
Alarm condition.Amber
System in pass-through mode.OffFailover (FO)
System has completed a line card failover and is still in the failover
configuration.
Blue
Communication link to the Cisco uBR10012 router is not established.OffCOM 0/COM
1
Communication link with the Cisco uBR10012 router is established.Green
The controller card provides the following high-level status information to the PRE:
•
General health of the Cisco UBR-RFSW-ADV
•
Version information
•
Command history
•
Command status (success or failure)
•
Operational status (active or standby status of the relays)
•
Status of switchover or revertback request sent by the PRE
For information about the controller PIDs, see Cisco UBR-RFSW-ADV Components Part Numbers and
Product Identifiers.
