Figure 2: Cisco UBR-RFSW-ADV — Rear View (CMTS Side)
Downstream Switch Card3Upstream Switch Card1
—
Upstream and Downstream Protect Cards2
The figure below shows the front view (cable plant side) of the upstream-only version of the
Cisco UBR-RFSW-ADV.
Figure 3: Upstream-Only Version of Cisco UBR-RFSW-ADV — Front View (Cable Plant Side)
Power supply module3Upstream interconnect card1
—
Controller card2
Cisco uBR Advanced RF Switch Hardware Installation Guide
OL-24104-01 3
