Cisco UCS C22 M3 Spec Sheet

Cisco UCS C22 M3 High-Density SFF Rack-Mount Server
CONFIGURING the SERVER
15
Approved Configurations
(1) 1-CPU configuration without memory mirroring:
■ Select from 1 to 6 DIMMs. Refer to Memory Population Rules, page 51, for more detailed
information.
(2) 1-CPU configuration with memory mirroring:
■ Select either 2 or 4 DIMMs. The DIMMs will be placed by the factory as shown in the following
table:
■ Select the memory mirroring option (N01-MMIRROR) as shown in Table 4 on page 14.
(1) 2-CPU configuration without memory mirroring:
■ Select from 1 to 6 DIMMs per CPU (2 to 12 DIMMs total). Refer to Memory Population Rules,
page 51, for more detailed information.
(2) 2-CPU configuration with memory mirroring:
■ Select 2 or 4 DIMMs per CPU (4 or 8 DIMMs total). The DIMMs will be placed by the factory as
shown in the following table
:
■ Select the memory mirroring option (N01-MMIRROR) as shown in Table 4 on page 14.
Number of
DIMMs
DIMM Placement in Channels
(Channel A is not used with memory mirroring)
2 CPU 1: 1 DIMM in Channel B, 1 DIMM in Channel C
4 CPU 1: 2 DIMMs in Channel B, 2 DIMMs in Channel C
Number of
DIMMs per
CPU
DIMM Placement
(Channels A and D are not used with memory mirroring)
2 CPU 1:
1 DIMM in Channel B
1 DIMM in Channel C
CPU 2:
1 DIMM in Channel E
1 DIMM in channel F
4 CPU 1:
2 DIMMs in Channel B
2 DIMMs in Channel C
CPU 2:
2 DIMMs in Channel E
2 DIMMs in Channel F
NOTE: System performance is optimized when the DIMM type and quantity are equal
for both CPUs.
