Cisco UCS C22 M3 High-Density SFF Rack-Mount Server
24
CONFIGURING the SERVER
STEP 6 SELECT PCIe OPTION CARD(s)
The standard PCIe card offerings are:
■ Converged Network Adapters (CNAs)
■ Network Interface Cards (NICs)
■ Host Bus Adapters (HBAs)
Select PCIe Option Cards
The available PCIe option cards are listed in Table 8.
Table 8 Available PCIe Option Cards
Product ID (PID) PID Description
Card
Height
Converged Network Adapters (CNAs)
UCSC-PCIE-CSC-02 Cisco VIC 1225 Dual Port 10Gb SFP+ CNA Half
UCSC-PCIE-C10T-02 Cisco VIC 1225T Dual Port 10GBaseT CNA Half
UCSC-PCIE-C40Q-02 Cisco VIC 1285 Dual Port 40Gb QSFP CNA Half
UCSC-PCIE-QSFP
1
Qlogic QLE8242-CU dual-port 10 GbE FCoE CNA Half
UCSC-PCIE-ESFP Emulex OCe11102-FX dual-port 10 GbE FCoE CNA Half
UCSC-PCIE-Q8362 Qlogic QLE8362 dual-port 10 GbE FCoE CNA Half
Network Interface Cards (NICs)
N2XX-ABPCI01-M3 Broadcom 5709 Dual-Port Ethernet PCIe Adapter w/TOE for M3 Servers Half
N2XX-ABPCI03-M3 Broadcom 5709 Quad Port 10/100/1Gb NIC w/TOE iSCSI for M3 Servers Half
UCSC-PCIE-BTG Broadcom 57712 Dual Port 10GbE 10G-BaseT w/TOE Half
N2XX-AIPCI01 Intel 10GbE 2-Port Niantec Controller with Copper SFP+ Cable Half
UCSC-PCIE-IRJ45 Intel Quad Port GbE controller (this is a quad-port i350 controller) Half
UCSC-PCIE-ITG Intel X540 Dual Port 10GBase-T Adapter Half
UCSC-PCIE-BSFP Broadcom NetXtreme II 57712 Dual Port 10 Gigabit Ethernet PCIe
Adapter Card with SFP+
Half
UCSC-PCIE-B3SFP BROADCOM 57810 10Gb AFEX SFP+ Half
Host Bus Adapters (HBAs)
N2XX-AEPCI03 Emulex LPe 11002, 4Gb Fibre Channel PCIe Dual Channel HBA Half
N2XX-AEPCI05 Emulex LPe 12002, 8Gb dual port Fibre Channel HBA Half
N2XX-AQPCI03 Qlogic QLE2462, 4Gb dual port Fibre Channel HBA Half
N2XX-AQPCI05 Qlogic QLE2562, 8Gb dual port Fibre Channel HBA Half
UCSC-PCIE-Q2672 Qlogic QLE2672-CSC, 16Gb Fibre Channel HBA with SR Optics Half
UCSC-PCIE-E16002 Emulex LPe16002-M6, 16Gb Fibre Channel HBA with SR Optics Half
