Cisco UCS C22 M3

Cisco UCS C22 M3 High-Density SFF Rack-Mount Server
CONFIGURING the SERVER
23
Approved Configurations
(1) Embedded RAID (LSI MegaSR)
■ Select up to eight SAS/SATA drives (note that none of the RAID configuration options listed in
Tab le 6 on page 18 can be chosen for embedded RAID). You can mix SAS and SATA drives.
(2) LSI MegaRAID 9270CV-8i (with data cache and supercap), LSI MegaRAID 9240-8i, and LSI
MegaRAID 9220-8i
■ Select up to eight SAS/SATA drives listed in Table 7 on page 22. You can mix SAS and SATA
drives.
(3) LSI MegaRAID 9220-4i
■ Select up to four SAS/SATA drives listed in Table 7 on page 22. You can mix SAS and SATA
drives.
(4) None of the Above
■ If you did not select embedded RAID or a PCIe RAID controller, you can only select up to four
SATA drives, which will be controlled by the embedded SATA-only RAID controller.
Caveats
■ You can mix SATA and SAS drives
■ If you select one or more SAS drives, you must select either a PCIe RAID controller from
Tab le 6 on page 18 or an embedded RAID option from Table 5 on page 18.
■ If you select four or less SATA-only drives, you can select a PCIe RAID controller from
Tab le 6 on page 18 or an embedded RAID option from Table 5 on page 18, or neither. If
you select neither, the drives will be controlled by the embedded SATA-only RAID controller.
NOTE: The number of RAID groups (virtual drives) supported per controller is as
follows:
■ LSI MegaRAID SAS 9270CV-8i RAID controller card = 64
■ LSI MegaRAID 9240-8i RAID controller card = 16
■ LSI MegaRAID 9220-8i RAID controller card = 16
■ LSI MegaRAID 9220-4i RAID controller card = 16
