Cisco UCS C22 M3 Spec Sheet

Cisco UCS C22 M3 High-Density SFF Rack-Mount Server
BASE SERVER STANDARD CAPABILITIES and FEATURES
7
Storage controller The following RAID options are available:
■ Embedded RAID (3 Gbps) (these implementations of RAID do not
consume a PCIe slot).
• Embedded SATA-only RAID controller, supporting up to four SATA-only
drives (RAID 0, 1, 10), or
• ROM5 RAID upgrade, supporting up to eight SAS+SATA drives (RAID 0,
1, 10), or
• ROM55 RAID upgrade, supporting up to eight SAS+SATA drives (RAID 0,
1, 5, 10).
■ PCIe RAID controllers (these consume PCIe slots)
• LSI MegaRAID 9270CV-8i with 1 GB Transportable Memory Module
(TMM) data cache and chassis-mounted (remote) supercap for data
cache power backup, supporting RAID 0, 1, 5, 6, 10, 50, and 60 and
up to eight internal SAS+SATA drives.
• LSI MegaRAID 9240-8i RAID 8-port PCIe RAID controller, supporting
RAID 0, 1, 5, 10, and 50 and up to eight internal SAS+SATA drives.
• LSI MegaRAID 9220-8i RAID 8-port PCIe RAID controller supporting
RAID 0, 1, and 10 and up to eight internal SAS+SATA drives.
• LSI MegaRAID 9220-4i RAID 4-port PCIe RAID controller supporting
RAID 0, 1, and 10 and up to four internal SAS+SATA drives.
Interfaces ■ Rear panel
• One DB9 serial port connector
• Four USB 2.0 port connectors
• One DB15 VGA connector
• One 10/100/1000 Ethernet management port
• Two 1 GbE (10/100/1000 Mbps capable) Ethernet LOM ports
■ Front panel
•Two USB 2.0 ports
Front Panel ■ A front panel controller provides status indications and control buttons
Power subsystem One 450 W power supply or one 650 W power supply, depending on server
configuration and loading. Prior to making a power supply selection, the UCS
Power Calculator should be run to determine the right size power supply for
your server configuration. A fully configured C22 M3 server may require the
650 W power supply. The UCS Power Calculator can be found at the following
link:
https://express.salire.com/Go/Cisco/Cisco-UCS-Power-Calculator.aspx
Fans Chassis:
■ Five fans for front-to-rear cooling. N + 1 redundant.
Power supply:
■ The power supply is equipped with a fan.
Capability/Feature Description
