Cisco UCS C-Series Servers Upgrade Guide for Intel Xeon v3 Series CPUs
Minimum Software and Firmware Requirements
Minimum Software and Firmware Requirements
Cisco UCS C460 M4 Minimum Software and Firmware Requirements
The minimum software and firmware versions required for the Cisco UCS C460 M4 server to support
Intel Xeon E7-4800 or E7-8800 v3 Series EX CPUs are as follows:
Low-Level Firmware Requirements
Note You will be directed to this section from the upgrade procedures only for cases in which you are not using
the Cisco Host Upgrade Utility or Cisco UCS Manager to upgrade the server firmware.
Low-level server firmware controls server components such as the power sequencer, field-programmable
gate arrays (FPGAs), and power supply units (PSUs).
Note The low-level firmware must be up-to-date before you upgrade the CPU hardware.
If you update the server BIOS and Cisco IMC management firmware by using the Cisco Host Upgrade
Utility (HUU) or the Cisco UCS Manager as directed in these procedures, the low-level firmware is
updated automatically. If you use any other method such as the Cisco IMC interface, you must manually
initiate the low-level firmware update.
• Initiating a Low-Level Firmware Update Using the Cisco IMC GUI interface, page 2
• Initiating a Low-Level Firmware Update Using the Cisco IMC CLI interface, page 3
Initiating a Low-Level Firmware Update Using the Cisco IMC GUI interface
Step 1 Log into the GUI interface for the server by using a browser and the IP address that was assigned to the
server.
Step 2 If not already powered on, power on the server by using the GUI interface.
Step 3 Power off the server by using the GUI interface.
• If the server’s low-level firmware is not up-to-date, a dialog appears with the following message:
Table 1 Cisco UCS C460 M4 Minimum Requirements for Intel Xeon v3 CPUs
Software or Firmware Minimum Version
Server Cisco IMC 2.0(6)
Server BIOS 2.0(6)
Low-level server firmware Updated automatically when Cisco IMC is updated using Cisco
Host Upgrade Utility or Cisco UCS Manager. Otherwise, check for
“update available” message as described in Low-Level Firmware
Requirements, page 2.
Cisco UCS Manager
(UCSM-managed system only)
2.2(5)

Cisco UCS C220 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
HDD interface	-
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
PCI Express slots version	3.0
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Power supply	770 W
Power supply input frequency	50 - 60 Hz
Chassis type	Rack (1U)
Trusted Platform Module (TPM) version	1.2
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux (Unbreakable Enterprise Kernel (UEK)) Oracle Solaris Ubuntu Server CentOS

Weight and Dimensions

Depth	756 mm
Width	430 mm
Height	43.2 mm
