Cisco UCS C-Series Servers Upgrade Guide for Intel Xeon v3 Series CPUs
Minimum Software and Firmware Requirements
Upgrade Scenario 3: Standalone Server RMA; BIOS on Spare Server is Earlier Than
the Minimum Version
This scenario is unique to a field-service situation in which a server that is already running Intel Xeon v3
Series CPUs must be replaced (RMA), but the only replacement server available is running a BIOS
earlier than the minimum version.
This scenario assumes the following conditions:
• The server is in standalone mode.
• The replacement server is using Intel Xeon v3 Series CPUs (after the CPUs are transferred from the
defective server).
• The replacement server is using DDR4 DIMMs and DDR4 memory risers (after the DIMMs and
memory risers are transferred from the defective server).
• The replacement server is using BIOS/Cisco IMC version earlier than the minimum version for your
server (see Minimum Software and Firmware Requirements, page 2).
Use the following procedure to upgrade the replacement server BIOS to the required version:
Step 1 After you transfer the Intel Xeon v3 Series CPUs, DDR4 DIMMs, and DDR4 memory risers from the
defective server to the replacement server, power on the replacement server.
Note The server does not boot because the BIOS is an earlier version than that required for the new
CPUs and memory.
The Cisco Host Upgrade Utility (HUU) that is normally recommended for upgrading the Cisco IMC and
BIOS cannot be used when the CPUs are non-bootable. However, the HUU ISO image contains a Zip
file that has the images required for updating the server through a browser. Continue with the following
steps to upgrade the server BIOS to the minimum version for your server (or later) by using a browser.
Step 2 Download the HUU ISO file for your minimum release (or later) from Cisco.com and save it on a laptop
or other computer.
Use the instructions in the Cisco Host Upgrade Utility User Guide for your release.
Step 3 Mount the ISO image.
Step 4 Extract the Zip file that is contained within the ISO image.
Note To determine the IP address of the target server so that you can log in to its Cisco IMC, you must
connect the server to a DHCP-enabled network, as described in the next step.
Step 5 Determine the IP address of the target server that you are upgrading:
a. Look at the physical MAC address label for the dedicated management port or the LOM1 port,
depending on which port is enabled by default in the target server.
b. Connect an Ethernet cable for your DHCP-enabled network to the dedicated management port or the
LOM 1 port.
Your DHCP server assigns an IP address to the port.
c. Query your DHCP server based on the MAC address of the port that you connected. The IP address
of the port that corresponds to the MAC address is listed.
Step 6 Use the Cisco IMC GUI in a browser to log in as administrator on the IP address of the target server.
Step 7 Use the Cisco IMC GUI to install and activate the Cisco IMC minimum version for your server (or later).

Cisco UCS C220 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
HDD interface	-
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
PCI Express slots version	3.0
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Power supply	770 W
Power supply input frequency	50 - 60 Hz
Chassis type	Rack (1U)
Trusted Platform Module (TPM) version	1.2
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux (Unbreakable Enterprise Kernel (UEK)) Oracle Solaris Ubuntu Server CentOS

Weight and Dimensions

Depth	756 mm
Width	430 mm
Height	43.2 mm
