Cisco UCS C480 M5 Service Manual

DescriptionFeature
The server supports one or two removable CPU modules, each
with two CPUs.
Up to four CPUs from the Intel Xeon Processor Scalable Family.
This includes CPUs from the following series:
• Intel Xeon Gold 5XXX Processors
• Intel Xeon Gold 6XXX Processors
• Intel Xeon Platinum 8XXX Processors
Central Processor
Each of the CPUs support up to 12 DIMMs for a total of 48
DIMMs.
The server supports up to two removable CPU modules, each with
24 DIMM sockets.
Memory
Multi-bit error protection is supportedMulti-bit error protection
BMC, running Cisco Integrated Management Controller (Cisco
IMC) firmware.
Depending on your Cisco IMC settings, Cisco IMC can be
accessed through the 1-Gb dedicated management port, the
1-Gb/10-Gb Ethernet LAN ports, or a Cisco virtual interface card.
Baseboard management
The network and management I/O ports for this server are on a
removeable I/O module:
• One 10/100/1000 Ethernet dedicated management port (RJ-45
connector)
• One 10/100/1000 Ethernet private inter-chassis port (RJ-45
connector)
• Two 1-Gb/10-Gb BASE-T Ethernet LAN ports (RJ-45
connectors)
• One RS-232 serial port (DB-9 connector)
• One VGA video connector port (DB-15 connector)
• Two USB 3.0 ports
Front panel:
• One front-panel keyboard/video/mouse (KVM) connector
that is used with the KVM cable, which provides two USB
2.0, one VGA, and one DB-9 serial connector.
Network and management I/O
The two 1-Gb/10-Gb BASE-T Ethernet LAN ports support the
wake-on-LAN (WoL) standard.
WoL
Cisco UCS C480 M5 Server Installation and Service Guide
10
Overview
Summary of Server Features
