Cisco UCS C480 M5 Service Manual

DescriptionFeature
A DVD drive module option is available in place of the right drive
bay module.
Other removable media
• Front-loading storage: the server has a dedicated internal
socket near the chassis front for a single storage controller
card (RAID or HBA). This controller card can control up to
24 front-loading drives.
• Internal, auxiliary storage. The server supports these options:
• When SAS/SATA drives are populated in the auxiliary
rear drive bays, they can be controlled by a storage
controller card in PCIe slot 11 or 10.
• When NVMe SSDs are populated in the auxiliary drive
bays, you must have an NVMe switch card in PCIe slot
10.
For a detailed list of storage controller options, see Supported
Storage Controllers and Cables, on page 133.
Storage management
The server supports the following options when RAID cards are
installed:
• There is a bracket on the chassis wall for a supercap unit that
backs up a front RAID controller for front-loading drives.
• There is a bracket on the rear drive module diffuser for a
supercap unit that backs up a rear RAID controller.
RAID supercap backup
Integrated VGA video.Integrated video
Cisco UCS C480 M5 Server Installation and Service Guide
12
Overview
Summary of Server Features
