Table 13: GPU Card Power Cables
Power Cable PIDDouble-Wide GPU Card
UCS-AMDCBL-C480M5AMD S7150 X2
UCS-P10CBL-C480M5NVIDIA Tesla M10
UCS-P100CBL-480M5NVIDIA Tesla M60
NVIDIA Tesla P40
NVIDIA Tesla P100 12GB
NVIDIA Tesla P100 16GB
NVIDIA Tesla V100
16GB
When using NVIDIA Tesla V100 16GB GPU cards in this server, there are special temperature requirements,
as described in the following table.
Caution
Table 14: C480 M5 Operating Temperature Requirements For Double-Wide GPU Cards
Maximum Server Operating Temperature (Air Inlet Temperature)GPU Card
35° C (95.0° F)AMD FirePro S7150 X2
35° C (95.0° F)NVIDIA Tesla M10
35° C (95.0° F)NVIDIA Tesla M60
35° C (95.0° F)NVIDIA Tesla P40
35° C (95.0° F)NVIDIA Tesla P100 12GB
35° C (95.0° F)NVIDIA Tesla P100 16GB
Differs by number of GPUs installed:
• Four or less GPUs installed: 35° C (95.0° F)
• More than four GPUs installed: 32° C (89.6° F)
NVIDIA Tesla V100 16
GB
For NVIDIA GPUs: The NVIDIA GPU card might be shipped with two power cables: a straight cable and
a Y-cable. The straight cable is used for connecting power to the GPU card in this server; do not use the
Y-cable, which is used for connecting the GPU card in external devices only (such as the Magma chassis).
For AMD GPUs: The correct power cable is a Y-cable (UCS-AMDCBL-C480M5).
Note
