Cisco WAP321 Datasheet

© 2012 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 4 of 8
●
Elegant, compact design with internal antennas and versatile mounting kit enables installation on a ceiling,
wall, or desktop.
●
Intelligent QoS prioritizes network traffic to keep critical network applications running at top performance.
●
Power-saving sleep mode and port control features help maximize energy efficiency.
●
Highly secure guest access enables safe wireless connectivity for visitors.
●
Support for IPv6 lets you deploy future networking applications and operating systems without
costly upgrades.
Specifications
Table 1 lists the specifications, package contents, and minimum requirements for the Cisco WAP321 Wireless-N
Selectable-Band Access Point with Single Point Setup.
Table 1. Specifications
Specifications Description
Standards IEEE 802.11n, 802.11g, 802.11b, 802.3, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.11i
(WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460)
Ports Ethernet, Power
Switch Power button (on/off)
Buttons Reset
Cabling type Category 5e or better
LEDs Power, Wireless, LAN
Operating system Linux
Physical Interfaces
Ports Gigabit Ethernet, 12V DC power with support for 802.3af PoE
Power supply Not included with access point, but supports external power 12V DC power jack (Energy Star 2.0 compliant
with Efficiency Level 5) and 802.3af PoE
Buttons Power (on/off) push button; Reset button
Lock slot Slot for Kensington lock
LED Power, Wireless, Ethernet
Physical Specifications
Physical dimensions (W x D x H) 6.66 x 6.67 x 1.38 in. (169.08 x 169.42 x 35 mm)
Weight 0.606 lb or 275g
PoE
PoE 802.3af
Peak PoE power 10.6W
Network Capabilities
Network protocols IEEE 802.11n, 802.11g, 802.11b, 802.3, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.11i
(WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460), RADIUS, syslog, HTTP/HTTPS,
Simple Network Management Protocol (SNMP)
VLAN support Yes
Number of VLANs 1 management VLAN plus 8 VLANs for SSID
Multiple SSIDs 8
802.1X supplicant Yes
802.11d No
SSID to VLAN mapping Yes
Auto channel selection Yes

Cisco WAP321 Specifications

General

Modulation	OFDM
Frequency band	2.4 - 5 GHz
Number of users	32 user(s)
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Certification	FCC class B, CE, IC, Wi-Fi
LED indicators	Power, WAN, WLAN
Supported network protocols	IEEE802.11b/g/n/i/e, 802.3, 802.3u, 802.1X, IPv4, IPv6, HTTP/HTTPS, SNMP
WAN connection	Wi-Fi
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA2, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	275 g
Dimensions (WxDxH)	169.08 x 169.42 x 35 mm
